Features of reduction motors

The main feature of the worm gear motor is that it has a reverse self-locking function and can have a large reduction ratio, and the input shaft and the output shaft are not on the same axis or on the same plane. However, the volume is generally larger, the transmission efficiency is not high, and the precision is not high.

The harmonic transmission of the reduction motor uses the controllable elastic deformation of flexible components to transmit motion and power. The input speed should not be too high. The advantages of planetary reduction motors are relatively compact structure, small return clearance, high precision, long service life, and large rated output torque. But the price is slightly more expensive. Gear reduction motors have the characteristics of small size and large transmission torque.

The gear reduction motor is designed and manufactured on the basis of a modular combination system. There are many motor combinations, installation forms and structural options. The transmission ratio is finely graded to meet different working conditions and achieve electromechanical integration. The gear reduction motor has high transmission efficiency, low energy consumption and superior performance. The cycloidal pinwheel reduction motor is a transmission model that adopts the principle of cycloidal pin tooth meshing planetary transmission.
