Servo reduction motor installation steps

In the reduction motor family, planetary reduction motors are widely used in servo, stepper, DC and other transmission systems due to their small size, high transmission efficiency, wide deceleration range, and high precision. Its function is to reduce the speed, increase the torque and reduce the load/motor inertia ratio on the premise of ensuring the transmission accuracy. In order to better help users make good use of planetary reduction motors, this article analyzes the reasons for the broken shafts of reduction motors and drive motors, and introduces in detail how to correctly install planetary reduction motors.

The correct installation, use and maintenance of reduction motors are important links to ensure the normal operation of mechanical equipment. Therefore, when installing a planetary reduction motor, be sure to assemble and use it in strict accordance with the following installation and use related matters.

Before installation, first confirm whether the motor and reduction motor are intact, and strictly check whether the sizes of the parts connected to the motor and reduction motor match.

In the second step, unscrew the screws on the dust-proof hole on the outside of the reducer motor flange, adjust the PCS system clamping ring to align the side hole with the dust-proof hole, insert the inner hexagon and tighten it. After that, remove the motor shaft key.
