Introduction to the principles and uses of stepper motors

Stepper motor principle: A stepper motor is an open-loop control component that converts electrical pulse signals into angular displacement or linear displacement. Under non-overload conditions, the motor's speed and stop position only depend on the frequency and number of pulses of the pulse signal and are not affected by load changes. That is, a pulse signal is added to the motor and the motor rotates by a step angle.

The existence of this linear relationship, coupled with the fact that stepper motors only have period errors and no cumulative errors, make it very simple to use stepper motors to control speed, position and other control areas. Although stepper motors have been widely used, stepper motors are different from ordinary DC motors. AC motors are commonly used. It must be used by a control system composed of double-ring pulse signals, power drive circuits, etc. Therefore, it is not easy to use stepper motors well. It involves many professional knowledge such as mechanics, electrical machinery, electronics and computers.

Purpose of stepper motor: Stepper motor is an open-loop control component that converts electrical pulse signals into angular displacement or linear displacement. Under non-overload conditions, the motor's speed and stop position only depend on the frequency and number of pulses of the pulse signal and are not affected by load changes. That is, a pulse signal is added to the motor and the stepper servo motor rotates one step. The existence of this linear relationship, coupled with the fact that stepper motors only have periodic errors and no cumulative errors. It makes it very simple to use stepper motors to control speed, position and other control areas.
