What is the function of plastic hard tooth surface reduction motor?

The plastic hard-tooth surface reduction motor is a hard-tooth surface reduction motor for plastic granulators. It is a modified hard-tooth surface reduction motor on the plastic granulator to achieve better extrusion deceleration effects.

Here we first take a look at the professional knowledge corresponding to the reduction motor:

Reduced motor: Reduced motor is generally used for motor equipment with low speed ratio and high torque. An electric motor, gas turbine or other high-speed energy source is connected to a large gear on the output shaft through the input shaft of the reduction motor. In order to achieve the purpose of deceleration, the general deceleration motor will also have several gears with the same basic principle to achieve the actual effect of dream deceleration. The ratio of the gear modules of the large gear and the small gear is the reduction ratio.

What is the function of plastic hard tooth surface reduction motor?

Gear: A mechanical component with teeth on the edge that can continuously mesh to transmit the power of exercise. It is a toothed mechanical part that meshes with each other. The hole in the large gear is twice the diameter of the small gear. If the large gear does not move and the small gear rotates around the large gear, how many times will the small gear rotate at a constant speed? On the contrary, if the small gear does not move and the large gear rotates around the small gear, how many weeks will the large gear rotate at a constant speed? When the large gear does not move, the small gear rotates around the large gear once, and the small gear rotates at a constant speed; when the small gear does not move, the large gear rotates around the small gear once, and the large gear rotates at a constant speed for one and a half times, that is, 240° rotates at a constant speed, and the 360° part It rotates at a constant speed for one and a half times, the 480° part rotates at a constant speed for two weeks, and the 720° part rotates at a constant speed for three weeks.

Tooth surface hardening: The load-bearing capacity of the gear tooth surface should be related to the tooth surface strength. The higher the strength, the higher the load-bearing capacity. According to the strength of the tooth surface, we usually divide the gear transmission system into two categories, namely, hard tooth surface gear transmission system and soft tooth surface gear transmission system. Usually a pair of meshing gears whose tooth surface strength exceeds 350HBS are called hard tooth surface gears, otherwise they are called soft tooth surface gears.

The advantages of hard bottom gear reduction motors are as follows:

1. The gear is made of high toughness, low carbon, environmentally friendly carbon steel, carburized and quenched. The tooth surface layer strength is HRC58-62. The gears all adopt CNC machine tool cutting technology, with high precision and good feel.

2. High transmission rate: more than 96.5 for single pole, more than 93 for bipolar, and more than 90 for three-level.

Based on the high precision of the hard tooth surface reduction motor, the plastic granulator can effectively grasp the actual effect of deceleration adjustment, making the plastic granulator more integrated, intelligent and efficient in production and manufacturing operations!
